import axi
BOUNDS = (0,0,11.75,8.25)
# Set this variable to true when you wish to draw with the plotter.
draw = False
def main():
#letter C
turtle = axi.Turtle()
turtle.pu() #pen up
turtle.goto(1,4) # go to point (1,4)
turtle.pd() # pen down
r = 1 # radius for the curve quarter circle of C
turtle.circle(r, -90, 100) # draw a circular shape with radius r and covering -90° (quarter circle) constituted of 100 lines
turtle.goto(0,6) # go to point (0,6)
r = 1 # radius for the curve quarter circle of C
turtle.circle(r, -90, 100) # draw a circular shape with radius r and covering -90° (quarter circle) constituted of 100 lines
turtle.goto(4,7) # go to point (4,7)
r = 1 # radius for the curve quarter circle of C
turtle.circle(r, -90, 100) # draw a circular shape with radius r and covering -90° (quarter circle) constituted of 100 lines
turtle.goto(5,5) # go to point (5,5)
r = 1 # radius for the curve quarter circle of C
turtle.circle(r, -90, 100) # draw a circular shape with radius r and covering -90° (quarter circle) constituted of 100 lines
turtle.pu() #pen up
#letter D
turtle.goto(0,3) # go to point (0,3)
turtle.pd() # pen down
turtle.goto(5,3) # go to point (5,3)
turtle.goto(5,1) # go to point (5,1)
turtle.right(90) # rotate 90° to the right
r = 1 # radius for the curve quarter circle of D
turtle.circle(r, -90, 100) # draw a circular shape with radius r and covering -90° (quarter circle) constituted of 100 lines
turtle.goto(1,0) # go to point (1,0)
r = 1 # radius for the curve quarter circle of D
turtle.circle(r, -90, 100) # draw a circular shape with radius r and covering -90° (quarter circle) constituted of 100 lines
turtle.goto(0,3) # go to point (0,3)
turtle.pu() #pen up
turtle.home
# Scale letter to fit A4-sized paper
drawing = turtle.drawing.rotate_and_scale_to_fit(11.75, 8.25, step=90, padding=0.25)
# Render drawing
im = drawing.render()
# Create an image file of the drawing
im.write_to_png('letterCD.png')
# Draw with the plotter if relevant
if draw:
axi.draw(drawing)
if __name__ == '__main__':
main()
